SpudsAvailable

Urinal Flange Yoke Spud Brass 2-1/4" with Rubber Washer

Brass 2-1/4 inch urinal flange yoke spud assembly with rubber washer.

Category: Spuds
Material: Brass
Alloy: Brass
Size: 2 1/4"
Shape: Yoke Flange Assembly
Availability: Available

Product Details

A brass 2-1/4 inch urinal flange yoke spud assembly for commercial urinal drain flange repair, outlet connection, restroom retrofit, and facility maintenance applications. The assembly includes a body, threaded bolts, washers, nuts, and rubber washer.

Applications

Commercial Plumbing
Urinal Repair
Outlet Connection
Facility Maintenance
Restroom Repair

Keywords

urinal flangeyoke spudbrass yoke spud2 1/4 spudrubber washerurinal drain flangecommercial plumbingrestroom repair

Specifications

Includes	Body, threaded bolts, washers, nuts, rubber washer
Material	Brass
Type	Urinal flange yoke spud assembly
Size	2 1/4"
Gasket / Washer	Rubber washer
Thread	2.25-11 1/2 NPT shown
Bolt Spread	6.062" shown
Body Diameter	2.687" shown
Opening Diameter	1.843" +/- 0.015 shown
Reference Diameter	2.125" shown
Washer Dimension	0.781" shown
Washer Thickness	0.437" shown
